Mine cable sheathing rubber compound (XH-03A-CV-I)
Mine cable sheathing rubber compound (XH-03A-CV-I)
Mine cable sheathing rubber compound (XH-03A-CV-I)
Mine cable sheathing rubber compound (XH-03A-CV-I)
Mine cable sheathing rubber compound (XH-03A-CV-I)
Mine cable sheathing rubber compound (XH-03A-CV-I)

Mine cable sheathing rubber compound (XH-03A-CV-I)

Advantages:

This series rubber compound is produced in accordance with the requirements of national standard GB7594.7-87, and accords with the regulation of mine industry standard MT818-2009.
This product can be used to manufacture heavy cable jacket which its conductor allowable work-temperature can stay at 65℃ for a long-term .It has excellent tenacity, oil-resistance, ozone resistance and fine flame resistance, it also can substitute CR rubber compound completely. The manufactured cable, particularly suitable for the long-term poor working conditions, Our red and yellow mineral cable jacket material can satisfy the Standard No.GB12972-91.

Leave Message Inquiry Online

Technical Requirement and Tested Capability

No.

Test   Item

Unit

Requirement

Result

Before Aging

Tensile  Strength               ≥

Mpa

11.0

12.9

Fracture  Extension  Rate       ≥

％

250

480

Air Box

Aging Test

Condition

Temperature

℃

75±2

75±2

Time

H

10×24

10×24

Tensile

Strength

≥

Mpa

／

14.0

Changing Rate    ≤

％

-15

8.5

Fracture

Extension Rate

Middle Value     ≥

％

200

470

Changing Rate    ≤

％

-25

-6.1

Heat-Traction

Test

Condition

Air  Temperature

℃

200±3

200±3

Loading Time

min

15

15

Machinery Tress

N／cm²

20

20

Extension Rate                 ≤

％

175

15

Permanent Deformation          ≤

％

25

0

Oil Immersion

Test

Condition

Oil Temperature

℃

100±2

100±2

Immersion Time

H

24

24

Changing Rate of Tensile Strengte  ≤

％

±40

3.9

Changing Rate of Fracture Extension≤

％

±40

-10

Anti-tearing

Test

Strength of Anti-tearing          ≥

N/mm

5.0

7.5

Oxygen Index

38

Directory for usage

1、Extrusion: CPE has good heat-resistant and processing capability and wide extrusion temperature range, which enhance the safety for processing. For its hardness and viscosity are higher than neoprene, its extrusion temperature is correspondingly higher by 5-10 degrees.

                       Temperature range for stuffing port: 40-50℃

                       Temperature range for machine body:55-70℃

                       Temperature range for machine head: 65-80℃

2、In practical production, according to the difference of extruding machine and cable diameter, the processing parameter shall be adjusted. We will provide relevant technical data to our consumers after they buy our products and send experienced technicians to give on-site guidance.

3、Storage: it can be stored for more than six mouths. And it can still be used even though hardened after long time storage. It should be better for recycling if the conditions allows. Keep away from direct sunlight and raining.
